2-Way communication allows the 2WPGM to receive commands from Magellan Transceivers and then confirm the command. Backup Alarm Reporting option (activates PGM output if communication between the Magellan All-In-One- Consoles and the 2WPGM is lost)
Features:
- 1 fully programmable 5A relay output
- Deactivate PGM after event or timer
- Can be powered by the PA12
- Universal transmitter input (N.O/N.C)
- Typical wireless range with MG6160 and MG6250: 35m
- Typical wireless range with MG5050 and RTX3: 70m
- Universal transmitter input (N.O./N.C.)
- Anti-tamper switch
Specification
- Requires AC or DC input voltage (6V AC to 16.5V AC or 5V DC to 30V DC)
- Wireless frequency: 433MHz
- Dimensions: 12.5m x 4.6cm x 2.5cm
